Product Highlights
Automatic switch over between supplies.
Switches power when mains (utility) supply fails and switches back when mains (utility) supply returns.
Manual restore to S1.
Allows flexible control of source inputs.
Configurable inputs/outputs (2/6).
Provides multiple installation options.
Source 1/source 2 control.
Allows flexible control of source inputs.
Single-phase display.
Provides accurate information on the power supply phase.
Compatible with DSE160 power supply.
When no DC supply is available the DSE160 power supply connects to an AC power supply and then to the control module.
DSE Configuration Suite PC Software.
Provides complete user-friendly configuration and easy-to-use high-level system control & monitoring.
Specification
DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking.
MAXIMUM OPERATING CURRENT
61 mA at 12 V, 62 mA at 24 V
MAXIMUM STANDBY CURRENT
50 mA at 12 V, 51 mA at 24 V
OUTPUTS
AUXILIARY OUTPUTS A,B,C,D,E & F
2 A DC at supply voltage
VOLTAGE RANGE
15 V to 333 V AC (L-N)
FREQUENCY RANGE
3.5 Hz to 75 Hz
