Features
Voltage regulation less than +/-1%
Full wave rectifier
Single phase voltage sensing
Epoxy encapsulated to isolate humidity and increase vibration proof
Adjustable output voltage
Light weight, durable and economical
Specifications
Sensing Input
Voltage
16 to 25 Vac 50/60 Hz 1 phase 2 wire
Power Input
Voltage
60 to 100 Vac 50/60 Hz 1 phase 2 wire
Excitation Output
Voltage
Max. 100 Vdc @ power input 85 Vac
Current
Continuous 3A
Intermittent 5A for 60 seconds
Resistance
Min. 25 ohms
Voltage Regulation
Less than +/-1% (with 4% engine governing)
Build Up Voltage
2 Vac residual volts at power input terminal
Voltage Adjust Range
115/230 Vac +/-15%
Voltage Thermal Drift
Less than 5% at temperature range -40 to +70 °C
