DSE2131

DSENet® Ratiometric Input Expansion Module

The DSE2131 is a ratiometric input expansion module designed to give Original Equipment Manufacturers (OEMs) greater input flexibility when trying to meet complex industry generator control specifications.

The module includes ten inputs. These can be configured to connect to resistive sensors, 0-10 V DC signals or 4-20mA signals, analogue inputs. All configurations are controlled within the host control module.

OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)

WEIGHT
0.22kg

หมวดหมู่:
เพิ่มรายการลงในใบเสนอราคา
เปรียบเทียบสินค้า

Product Highlights

DIN rail & chassis mount.

Power on/link lost LED.

1.2km (0.75 Mile) working range.

Connect maximum of 4 x DSE2131’s to a single host controller.

Rotary ID switch to select address of DSE2131 to talk with host module when multiple DSE2131 modules are in use.

Max of 40 configurable inputs.

Specification

DC SUPPLY

CONTINUOUS VOLTAGE RATING
8V to 35V continuous

CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs will not be maintained during cranking.

MAXIMUM OPERATING CURRENT
292 mA at 12 V, 167 mA at 24 V

MAXIMUM STANDBY CURRENT
101 mA at 12 V, 66 mA at 24 VINPUTS
10 inputs configurable for digital/resistive (3k ohms) 4-20 mA and 0-10 V DC
