Features
Multi-VDC
Switchable Droop Control
Adjustable PID
Idle Speed Adjustment
Auxiliary Accessory Inputs
Speed Ramping
Soft Coupling
SPECIFICATIONS
PERFORMANCE
Isochronous Operation
± 0.25% or better
Speed Range / Governor
1 – 7.5 KHz Continuous
Speed Drift with Temperature
±1% Maximum
Idle Adjust CW
60% of Set Speed
Idle Adjust CCW
Less than 1200 Hz
Droop Range
1 – 5% regulation
Droop Adj. Max. (K-L Jumpered)
400 Hz., ±75 Hz per 1.0 A change
Droop Adj. Min. (K-L Jumpered)
15 Hz., ±75 Hz per 1.0 A change
Speed Trim Range
± 200 Hz
Remote Variable Speed Range
500 – 7.5 KHz
Terminal Sensitivity
J 100 Hz., ±15 Hz/Volt @ 5.0 K Impedance
L 735 Hz., ±60 Hz/Volt @ 65 K Impedance
N 148 Hz., ±10 Hz/Volt @ 1 Meg Impedance
P 10 VDC Supply @ 20 mA Max
INPUT / OUTPUT
DC Supply
12-24 VDC Battery Systems
Transient and Reverse Voltage Protected
Polarity
Negative Ground (Case Isolated)
Power Consumption
50mA continuous plus actuator current
Speed Signal Range
Speed Sensor Signal
1.0-50 VAC
1.0 – 120 Volts RMS
Actuator Current Range
@ 77°F (25°C)
Min. 1.0 A
Max. 10 A
RELIABILITY
Vibration
1G @ 20-100 Hz
Testing
100% Functionally Tested
ENVIRONMENTAL
Ambient Temperature
-40° to 85°C (-40 to 180°F)
Relative Humidity
up to 95%
All Surface Finishes
Fungus Proof and Corrosion Resistant
COMPLIANCE / STANDARDS
Agency
CE (EN55011, EN50081-2, EN50082-2), RoHS, Lloyds Register, DNV/GL, Bureau Veritas
PHYSICAL
Weight
1.2 lb. (0.544 kg)
Mounting
Any position, Vertical Preferred
